INTEGRATED LITHIUM-ION PROVIDES SIMPLICITY AND REDUCES COST

Many businesses know that it takes Lithium-ion to get the most efficiency, uptime and cost effectiveness out of an electric forklift. And now customers are learning that it takes an integrated power source for simplicity of operation and optimal ergonomics. The Big Joe LVE35 delivers all of the above—an optimal package that supports the operator while driving down cost of operations. Big Joe is one of the few suppliers to develop and produce both forklift and battery, so customers have one expert supplier to help from end to end.

Charging Made Easy

Every LVE35 forklift comes standard with an onboard charger that plugs into a typical singlephase 120V or 240V wall outlet, allowing you to recharge almost anywhere. For operations that require faster charge rates, offboard chargers that conveniently connect to the truck’s integrated charge port are available. Since the battery doesn’t need to cool down after charging, your truck can spend more time working. Unlike some other suppliers, Big Joe provides—and supports—the forklift, battery and charger.

A Battery without Headaches

The Lithium-ion battery is completely maintenance-free. That means no watering, toxic fumes or corrosive and explosive gases. And you only need one battery per truck—no cranes, hoists or roller systems for swapping batteries are required. This simplicity not only saves space in your warehouse—it also reduces overhead since staffing doesn’t need to be dedicated to battery services.

Specifications


General Data
Load Capacity (lbs./kgs.)
3500
Load Center
24
Power Type
Battery
Operator Position
Seated
Tire Type
Pneumatic-shaped solid
Wheels (x=driven)
2x / 2
Exterior Dimensions
Free-Lift (in.)
60.2
Tilt Range (deg)
3 / 5
Overall Width (in.)
43.3
Mast Lowered Height (in.)
88.2
Mast Extended Height (in.)
230
Overhead Guard Height (in.)
81.8
Turning Radius (in.)
61
Load Distance (in.)
16.6
Lift Height (under twistlocks) (in.)
189
Performance
Maximum Travel Speed - Full Load (mph)
8
Maximum Travel Speed - No Load (mph)
8.7
Lifting Speed - Full Load (fpm)
65
Lifting Speed - No Load (fpm)
88.6
Lowering Speed - Full Load (fpm)
78.7
Lowering Speed - No Load (fpm)
86.6
Gradeability - Maximum - Full Load
10
Gradeability - Maximum - No Load
15
Truck Weights
Total Weight (lb.)
7645
Tires
Size - Front
18x7-8
Size - Rear
15x4.5-8
Wheelbase (in.)
52.4
Tread Width - Front (in.)
37.1
Underclearance -Center of Wheelbase (in.)
3.6
Brake - Service / Parking
Hydraulic / Mechanical
Tread Width - Rear (in.)
6.9
Auxiliary Hydraulic Function Specifications
Max. Operating Pressure (psi)
2750
Battery Features
Voltage/Capacity
80 / 230
