Specifications


General Data
Load Capacity (lbs./kgs.)
5000
Load Center
24 (600)
Power Type
Battery
Operator Position
Seated Rider
Tire Type
Cushion
Wheels (x=driven)
2x / 2
Exterior Dimensions
Free-Lift (in.)
57.8
Fork Size (T x W x L) (in.)
1.6 x 4.8 x 42
Tilt Range (deg)
5 / 6
Length to Fork Face (in.)
87
Overall Width (in.)
42.5
Overhead Guard Height (in.)
83
Turning Radius (in.)
75.6
Basic Right-Angle Stacking Aisle Width (in.)
93.9
Performance
Maximum Travel Speed - Full Load (mph)
9
Maximum Travel Speed - No Load (mph)
9.3
Lifting Speed - Full Load (fpm)
74.8
Lifting Speed - No Load (fpm)
98.4
Lowering Speed - Full Load (fpm)
88.5
Lowering Speed - No Load (fpm)
98.4
Gradeability - Maximum - Full Load
15
Gradeability - Maximum - No Load
16
Truck Weights
Total Weight (lb.)
10538
Tires
Size - Front
21x7-15
Size - Rear
16x6-10.5
Wheelbase (in.)
55.3
Tread Width - Front (in.)
35.6
Underclearance - Minimum with Load (in.)
35.4
Underclearance -Center of Wheelbase (in.)
4.7
Brake - Service / Parking
Hydraulic/ Mechanical
Auxiliary Hydraulic Function Specifications
Max. Operating Pressure (psi)
2750
Battery Features
Voltage/Capacity
80 / 460
