Model LPT40 DSD

The LPT40 Direct Store Delivery (DSD) configuration is an industry-exclusive solution aimed at changing the store delivery process forever. When used with the SlimSavr design, operations will:

Eliminate waste by reducing touches
Reduce labor, simplify the check-in process
Reduce fatigue
Reduce the likelihood of injuries from lifting
Be able to navigate through tight spaces
Not damage floors
Not be required to modify shrink wrap machines

Request A Quote Request Rental Quote

Apply For Financing

Features

Specifications

General Data

Load Capacity (lbs./kgs.)

4000

Load Center

24 (600)

Operator Position

Pedestrian

Wheels (x=driven)

1x / 2

Exterior Dimensions

Fork Size (T x W x L) (in.)

1.97 x 6.22 x 41.33

Fork Spread Max. / Min. (in.)

Length to Fork Face (in.)

15.7

Overall Width (in.)

Turning Radius (in.)

51.4

Overall Length (in.)

58.3

Lowered Height (in.)

3.3

Distance from Bumper to Center of Drive Tire (in.)

32.4

Performance

Maximum Travel Speed - Full Load (mph)

3.1

Maximum Travel Speed - No Load (mph)

3.4

Lifting Speed - Full Load (fpm)

3.9

Lifting Speed - No Load (fpm)

4.9

Lowering Speed - Full Load (fpm)

12.8

Lowering Speed - No Load (fpm)

Gradeability - Maximum - Full Load

Gradeability - Maximum - No Load

Truck Weights

Total Weight (lb.)

507

Tires

Size - Front

8.3 x 2.8

Size - Rear

2.9 x 3.5

Wheelbase (in.)

43.5

Underclearance -Center of Wheelbase (in.)

0.7

Brake - Service / Parking

Electromagnetic

Tread Width - Rear (in.)

13.8

Tire Size - Casters (front) (in.)

2.9 x 1.1

Battery Features

Voltage/Capacity

48 / 30
