Features
Specifications
General Data
Load Capacity (lbs.)
4000
Power Type
Diesel
Operator Position
Seated Rider
Tire Type
Pneumatic
Wheels (x=driven)
2x / 2
Exterior Dimensions
Maximum Fork Height (MFH) (in.)
131.5
Free-Lift (in.)
6.1
Fork Size (T x W x L) (in.)
1.6 x 5 x 42
Fork Spread Max. / Min. (in.)
40 / 10
Tilt Range (deg)
6º / 11º
Length to Fork Face (in.)
101.8
Overall Width (in.)
45.3
Mast Lowered Height (in.)
84.5
Mast Extended Height (in.)
179.5
Overhead Guard Height (in.)
83.1
Turning Radius (in.)
90.9
Load Distance (in.)
18.5
Rear Overhang (in.)
18.3
Basic Right-Angle Stacking Aisle Width (in.)
109.4
Performance
Maximum Travel Speed - Full Load (mph)
11.2 / 10.9
Maximum Travel Speed - No Load (mph)
11.5 / 11.5
Lifting Speed - Full Load (fpm)
117
Lifting Speed - No Load (fpm)
123
Lowering Speed - Full Load (fpm)
99
Lowering Speed - No Load (fpm)
94
Drawbar Pull - Max. - Full Load (fpm)
4630
Drawbar Pull - Max. - No Load (fpm)
2430
Gradeability - 1 mph - Full Load
35%
Gradeability - Maximum - Full Load
43%
Gradeability - Maximum - No Load
22%
Truck Weights
Total Weight (lb.)
7480
Weight Distribution - Full Load (front / rear) - (lb.)
10210 / 1680
Weight Distribution - No Load (front / rear) - (lb.)
3220 / 4260
Tires
Number (front / rear)
2 / 2
Size - Front
7.00-12-12PR
Size - Rear
6.00-9-10PR
Wheelbase (in.)
65
Tread Width (in.)
37.8 / 38.0
Underclearance - Minimum with Load (in.)
3.7
Underclearance -Center of Wheelbase (in.)
5.5
Brake - Service / Parking
Hydraulic / Mechanical
Power System
Battery (5-hour rating) (V/Ah)
12 / 76
Rated Horsepower @ rpm (SAE HP)
57 @ 2400 Net
Rated Torque @ rpm (SAE HP)
145 @ 1500 Net
Number of Cylinders
4
Piston Displacement (cu in)
148.5
Fuel Tank Capacity (US gal)
15.9
Transmission Type
Powershift
Transmission Speeds (forward / reverse)
1/1
Max. Operating Pressure (psi)
2275
Max. Flow Rate (gpm)
19
