Features
Specifications
General Data
Load Capacity (lbs.)
11000
Power Type
LP
Operator Position
Seated Rider
Tire Type
Pneumatic
Wheels (x=driven)
2x / 2
Exterior Dimensions
Maximum Fork Height (MFH) (in.)
120.5
Free-Lift (in.)
4.7
Fork Size (T x W x L) (in.)
2.4 x 6 x 48
Fork Spread Max. / Min. (in.)
45.7 / 11.8
Tilt Range (deg)
6 / 12
Length to Fork Face (in.)
124.8
Overall Width (in.)
57.1
Mast Lowered Height (in.)
96.5
Mast Extended Height (in.)
174.4
Overhead Guard Height (in.)
90.6
Turning Radius (in.)
110.5
Load Distance (in.)
21.9
Basic Right-Angle Stacking Aisle Width (in.)
134.5
Performance
Maximum Travel Speed - Full Load (mph)
13.4
Maximum Travel Speed - No Load (mph)
14
Lifting Speed - Full Load (fpm)
99
Lifting Speed - No Load (fpm)
101
Lowering Speed - Full Load (fpm)
106
Lowering Speed - No Load (fpm)
96
Drawbar Pull - Max. - Full Load (fpm)
7700
Drawbar Pull - Max. - No Load (fpm)
3700
Gradeability - 1 mph - Full Load
23
Gradeability - Maximum - Full Load
28
Gradeability - Maximum - No Load
21
Truck Weights
Total Weight (lb.)
16010
Weight Distribution - Full Load (front / rear) - (lb.)
24220 / 2820
Weight Distribution - No Load (front / rear) - (lb.)
6820 / 9190
Tires
Number (front / rear)
2 / 2
Size - Front
300-15-20PR
Size - Rear
7.00-12-12PR
Wheelbase (in.)
78.7
Tread Width (in.)
45.3 / 43.3
Underclearance - Minimum with Load (in.)
4.7
Underclearance -Center of Wheelbase (in.)
9.1
Brake - Service / Parking
Hydraulic <wet> / Hand
Power System
Battery (5-hour rating) (V/Ah)
12 / 35
Rated Horsepower @ rpm (SAE HP)
87@2330
Rated Torque @ rpm (SAE HP)
212@1500
Number of Cylinders
4
Piston Displacement (cu in)
224
Fuel Tank Capacity (US gal)
32
Transmission Type
Powershift
Transmission Speeds (forward / reverse)
2 / 2
Max. Operating Pressure (psi)
2630
Max. Flow Rate (gpm)
33.8
