Features
Specifications
General Data
Load Capacity (lbs./kgs.)
4500
Load Center
24 (600)
Power Type
Battery
Operator Position
Stand-Up Rider
Tire Type
Polyurethane
Wheels (x=driven)
1x / 1 / 4
Exterior Dimensions
Maximum Fork Height (MFH) (in.)
542
Free-Lift (in.)
187
Fork Size (T x W x L) (in.)
1.75 x 4 x 42
Fork Spread Max. / Min. (in.)
15 / 30
Tilt Range (deg)
3 / 4.5
Length to Fork Face (in.)
69.7
Overall Width (in.)
32
Mast Lowered Height (in.)
230
Mast Extended Height (in.)
578
Turning Radius (in.)
89
Overall Length (in.)
92
Lowered Height (in.)
3
Power Unit Width
49.5
Power Unit Height
60
Base Legs Overall Width (OAW)
6
Distance from Bumper to Center of Drive Tire (in.)
11.35
Performance
Maximum Travel Speed - Full Load (mph)
6.5
Maximum Travel Speed - No Load (mph)
7.5
Lifting Speed - Full Load (fpm)
90
Lifting Speed - No Load (fpm)
168
Lowering Speed - Full Load (fpm)
230
Lowering Speed - No Load (fpm)
230
Gradeability - Maximum - Full Load
5
Truck Weights
Total Weight (lb.)
10316
Tires
Size - Front
13.5 x 6
Size - Rear
6 x 4
Wheelbase (in.)
69.4
Brake - Service / Parking
Electric Disc
Tire Size - Casters (front) (in.)
8 x 4
Power System
Battery Type
Lead Acid
Battery Features
Voltage/Capacity
36 / 1395
Battery Compartment Width (in.)
38.62
Battery Weight Maximum (lb.)
3600
Battery Weight Minimum (lb.)
3100
Electric Motors - Drive (60 minutes) (hp)
7.1
Control Type
AC / Transistor
