Features
Specifications
General Data
Load Capacity (lbs./kgs.)
6500
Power Type
Gasoline / LP
Operator Position
Seated Rider
Tire Type
Cushion
Wheels (x=driven)
2x / 2
Exterior Dimensions
Maximum Fork Height (MFH) (in.)
131.5
Free-Lift (in.)
5.3
Fork Size (T x W x L) (in.)
1.8 x 5 x 42
Fork Spread Max. / Min. (in.)
38.2 / 10
Tilt Range (deg)
6 / 10
Length to Fork Face (in.)
98.6
Overall Width (in.)
43.7
Mast Lowered Height (in.)
83.1
Mast Extended Height (in.)
179.7
Overhead Guard Height (in.)
80.7
Turning Radius (in.)
81.1
Load Distance (in.)
17.7
Rear Overhang (in.)
22.4
Basic Right-Angle Stacking Aisle Width (in.)
98.8
Performance
Maximum Travel Speed - Full Load (mph)
10.6
Maximum Travel Speed - No Load (mph)
10.6
Lifting Speed - Full Load (fpm)
98
Lifting Speed - No Load (fpm)
102
Lowering Speed - Full Load (fpm)
98
Lowering Speed - No Load (fpm)
98
Drawbar Pull - Max. - Full Load (fpm)
4200
Drawbar Pull - Max. - No Load (fpm)
1750
Gradeability - 1 mph - Full Load
21
Gradeability - Maximum - Full Load
25
Gradeability - Maximum - No Load
16
Truck Weights
Total Weight (lb.)
9860
Weight Distribution - Full Load (front / rear) - (lb.)
14120 / 2240
Weight Distribution - No Load (front / rear) - (lb.)
2990 / 6870
Tires
Number (front / rear)
2 / 2
Size - Front
21 x 8 x 15
Size - Rear
16 x 6 x 10-1/2
Wheelbase (in.)
58.5
Tread Width - Front (in.)
35.8
Underclearance - Minimum with Load (in.)
2.6
Underclearance -Center of Wheelbase (in.)
4.1
Brake - Service / Parking
Hydraulic / Foot
Tread Width - Rear (in.)
36
Power System
Battery (6-hour rating) (V/Ah)
12 / 35
Piston Displacement (cu in)
151
Fuel Tank Capacity (US gal)
11.9
Engine Make / Model
Kubota / WG2503
Rated Horsepower @ rpm (SAE HP)
56@2600 / 58@2600 Net
Rated Torque @ rpm (SAE HP)
122@1800 / 139@1600 Net
Number of Cylinders
4
Transmission Type
Powershift
Transmission Speeds (forward / reverse)
1 / 1
Max. Operating Pressure (psi)
2275
Max. Flow Rate (gpm)
20
